Vehicledigital develop and produce high-quality 1080P 4CH to 12CH mobile DVR for various vehicles. DVR adopts digital recording technology, which can be widely used in urban public transportation industry, with GPS tracking, real-time remote video monitoring, WIFI and alarm functions. Our DVR system can provide effective evidence for traffic accidents, improve driving safety, and is very suitable for vehicle monitoring and fleet management.
For different customers requests, we have optional AI functions.
With WiFi station and AP mode; AP mode can support that mobile directly connects to device for easy preview and configuration on mobile through WebUI.
Multiple trigger recording modes with 15 seconds pre-recording function: motion trigger, G-sensor trigger, over-speeding trigger, 6-channel customized alarm input trigger, panic button trigger recording, and DMS/ADAS/BSD warning trigger.
Features:
Power:
Data Storage:
Transmission Interface:
Active Safety Warning System:
Technical Parameter:
Item |
Device Parameter |
Performance |
System |
Operating System |
Embedded Linux OS |
Operating Language |
Chinese/English/Russian |
|
Operating Interface |
GUI, Support mouse and remote control |
|
Audio & Video |
Video input |
4/6/8/10/12CH 1080P AHD/TVI/CVI/CVBS |
Video output |
VGA/HDMI+CVBS&AHD1080P |
|
Audio input |
4/6/8/10/12CH |
|
Audio output |
1CH Analog output |
|
Video Standard |
PAL/NTSC |
|
Video compression |
H.264/H264+/H.265/H265+ |
|
Image resolution |
1080P/720P/960H/D1/CIF |
|
Recording quality |
Class 1-6 optional |
|
Audio compression |
G711A/G711/G.726/MG.726/ADPCM/IMA |
|
Recording & Playback |
Storage method |
Private File System |
Video inquiry |
Inquiry by channel/Recording type/Alarm Type |
|
Local playback |
Playback by channels, time |
|
Local backup |
By SD card, USB disk |
|
FTP |
FTP firmware |
|
Firmware upgrading |
Upgrading mode |
Manual/Automatical/Remote/Emergency Recovery |
Upgrading method |
USB disk/Wireless network/SD card |
|
AV Output |
1CH VGA, 1CH M12-4PIN CVBS |
|
Power Input |
Power/Ignition signal |
|
Alarm input |
7 Digital input (Positive/Negative optional) |
|
Alarm input/output |
2 input/output optional |
|
ADC input |
4 ADC input |
|
Speed pulse |
1 |
|
RS232 |
1xRS232 |
|
TTL |
1xTTL |
|
RS485 |
1xRS485 |
|
CAN |
1xCAN optional |
|
Other interface |
LED Indication |
PWR/RUN |
HDD/SSD |
1xSATA 2.5” |
|
SD card |
1xSDXC High speed card (ip to 1x512GB) |
|
HDD lock |
1 |
|
Wireless interface |
GPS/BD/GLONASS |
GPS/BD/GLONASS |
Wifi |
802.11b/g/n, 2.4GHz |
|
3G/4G |
1xSMA,LTE/HSPA/WCDMA |
|
Active Safety interface |
ADAS |
1xADAS, 1080P/720P(AV2) optional |
DSM |
1xDSM, 1080P/720P(AV1) optional |
|
BSD |
1xBSD, 1080P/720P(AV3) optional |
|
Others |
Power Input |
DC: 8V~36V |
Power consumption |
22W(not including peripheral) |
|
Power output |
5V@500mA |
|
Working Temperature |
-20 — 70℃ |
|
Storage Size (H.265) |
1080P 0.726G/Hour/Channel |
|
Dimension |
162mm*180mm*76.5mm |
